- Technical Parameter
| Product Attributes | |
|---|---|
| Categories | Discrete Semiconductor Products > Transistors - FETs, MOSFETs - Single |
| Series | HEXFET® |
| Packaging | Tube |
| Part Status | Active |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 55V |
| Current - Continuous Drain (Id) @ 25°C | 110A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Vgs(th) (Max) @ Id | 4V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 146nC @ 10V |
| Input Capacitance (Ciss) (Max) @ Vds | 3247pF @ 25V |
| Vgs (Max) | ±20V |
| FET Feature | - |
| Power Dissipation (Max) | 200W (Tc) |
| Rds On (Max) @ Id, Vgs | 8 mOhm @ 62A, 10V |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole |
| Supplier Device Package | TO-220AB |
| Package / Case | TO-220-3 |
| Additional Resources | |
|---|---|
| Standard Package | 50 |
| Other Names | *IRF3205PBF 64-0085PBF 64-0085PBF-ND SP001559536 |
| Datasheet | |
|---|---|
| IRF3205 | |
- Commodity Description
Nice to meet you, dear. :)
If you're looking for the best company to buy components from, you've come to the right place.
If it's not listed then email us your part number or BOM for a quick quote.
Contact us: sales05@cgocmall.com / service@cgocmall.com
