- Technical Parameter
| Product Attributes | |
|---|---|
| Categories | Discrete Semiconductor Products |
| Series | HEXFET® |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 100V |
| Current - Continuous Drain (Id) @ 25°C | 9.4A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Vgs(th) (Max) @ Id | 4V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 25nC @ 10V |
| Input Capacitance (Ciss) (Max) @ Vds | 330pF @ 25V |
| Vgs (Max) | ±20V |
| FET Feature | - |
| Power Dissipation (Max) | 48W (Tc) |
| Rds On (Max) @ Id, Vgs | 210 mOhm @ 5.6A, 10V |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | D-Pak |
| Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 |
| Additional Resources | |
|---|---|
| Standard Package | 2,000 |
| Other Names | IRFR120NPBFTR IRFR120NTRPBF-ND IRFR120NTRPBFTR-ND SP001566944 |
| Datasheet | |
|---|---|
| IRFR/U120NPbF | |
- Commodity Description
Nice to meet you, dear. :)
If you're looking for the best company to buy components from, you've come to the right place.
If it's not listed then email us your part number or BOM for a quick quote.
Contact us: sales05@cgocmall.com / service@cgocmall.com
